UTM2545
This is 1:2 or 1:4 microphone transformer.
Recommended for any kind of NEVE-ish microphone inputs.
Description
A high performance, audio signal transformer for microphone level input applications. Useful for providing a 6 or 12 dB gain for any high impedance input. Suitable for any source balanced or unbalanced not exceeding 2.5kΩ. Dedicated to 1073 Neve style mic input.
Ratio: (1+1):(2+2)
Iimpedance: 1.2k:4.8k, 1.2k:1.2k, 300:4.8k, 300:1.2k
Frequency Rsponse @10kΩ source 10kΩ load: +/- 0.3 dB 15 Hz to 80 kHz (Ap)
Primary Inductance: 4.5H+4.5H @100Hz
Secondary Inductance: 36H+36H @100Hz
Total DC Resistance PRI: 58Ω
Total DC Resistance SEC: 140Ω
Max Level: @50Hz: +13 dBu
Mu-Metal, High Nickel Core, 79% Nickel Steel lamination
Additional information
| Weight | 0.2 kg |
|---|
