UTM2571
This is 1:1 line input or interstage, 10k:10k transformer, (10k:10k, 10k:2.5k, 2.5k:10k possible configurations).
Description
A high performance, audio signal transformer for line level input or interstage applications. Useful for providing a 6 dB gain for any high impedance input. Suitable for any source balanced or unbalanced not exceeding 5 kΩ. Works also well in the reverse (1:2).
Ratio: (1+1):(1+1)
Impedance: 10k:10k, 10k:2.5k, 2.5k:2.5k, 2.5k:10k
Frequency Response @10kΩ source 10kΩ load: +/- 0.5 dB 15 Hz to 80 kHz (Ap)
Primary Inductance: 140H+140H @100Hz
Secondary Inductance: 140H+140H @100Hz
Total DC Resistance PRI: 330Ω+330Ω
Total DC Resistance SEC: 400Ω+400Ω
Max Level: @50Hz: +28 dBu
Mu-Metal, High Nickel Core, 79% Nickel Steel lamination
Additional information
| Weight | 0.2 kg |
|---|
